FAG
Axial Spherical Roller Bearing
RFQ
EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.
The FAG 29232-E1-MB is an axial spherical roller bearing, 160 × 225 × 39 mm (bore × OD × width).
Parts from other brands with the same dimensions as the 29232-E1-MB include NSK 29232M, NTN 29232; check that the seal and clearance suffixes match before substituting.
| Symbol | Value | Description |
|---|---|---|
| ≈m | 4.6 kg | Weight |
| nG | 3,000 1/min | Limiting speed |
| nϑr | 1,450 1/min | Reference speed |
| Ca | 420,000 N | Axial Dynamic Load Rating (Ca) |
| C0a | 1,720,000 N | Axial Static Load Rating (C0a) |
| Cua | 218,000 N | Cua |
| Dbmin | 229 mm | Minimum bore diameter housing |
| dbmax | 168 mm | Maximum distance sleeve |
| d1 | 210 mm | Rip diameter shaft washer |
| A | 87 mm | Distance of the center point |
| Standard | Standard | |
| Without | Locating feature, housing washer | |
| Without | Handling thread holes | |
| Without | Test certificate |
| Symbol | Value | Description |
|---|---|---|
| d | 160 mm | Bore diameter |
| D | 225 mm | Outside diameter |
| B | 39 mm | Width |
| r1, 2 min | 1.5 mm | Minimum chamfer dimension |
| Symbol | Value | Description |
|---|---|---|
| da min | 195 mm | Min. shoulder diameter for mounting, inner ring |
| Da max | 204 mm | Max. shoulder diameter for mounting, housing |
| ra max | 1.5 mm | Max. fillet radius |
| Symbol | Value | Description |
|---|---|---|
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 200 °C | Operating temperature max. |
| Code | Description |
|---|---|
| MB | Cage |
| Standard bearing steel | Material |
| Tolerance class P0/PN2 / ABEC 1 | Tolerance class |
FAG 29232-E1-MB Axial Spherical Roller Bearing is a heavy-duty thrust bearing for very high axial loads while also accommodating a certain radial load. Its spherical raceway provides misalignment tolerance for extruders, cranes, vertical pumps, and heavy industrial axial support positions.
Asymmetrical barrel rollers and a spherical housing washer raceway transfer axial load through a large contact area. The self-aligning design benefits large equipment with shaft deflection or mounting inaccuracies.
Review axial load, speed, lubrication quantity, cooling, mounting alignment, and minimum load requirements.
All of these refer to this part. Hyphens, slashes and spaces are only a writing style.
29232E1MB29232 E1 MBRFQ
Same bearing type, bore × outside diameter × width and base designation, but seals, internal clearance, bore shape or precision may differ. Check the suffix before ordering.
