FAG
Radial Insert Ball Bearing
RFQ
EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.
The FAG UC201 is a plain radial insert ball bearing with no suffix, 12 × 47 × 31 mm (bore × OD × width).
The same specification also comes in an adjacent size: UC202 (15 mm bore).
| Symbol | Value | Description |
|---|---|---|
| ≈m | 0.193 kg | Weight |
| Cr | 13,600 N | Basic dynamic load rating, radial |
| C0r | 6,600 N | Basic static load rating, radial |
| Cur | 345 N | Fatigue load limit, radial |
| S | 12.7 mm | Distance raceway |
| d1 | 27.56 mm | Rib diameter inner ring |
| Ca | 4.2 mm | Distance to lubrication hole |
| A | 5 mm | A |
| f0 | 13.1 | Calculation factor |
| Symbol | Value | Description |
|---|---|---|
| d | 12 mm | Bore diameter |
| D | 47 mm | Outside diameter |
| B | 31 mm | Width |
| C | 17 mm | Width outer ring |
| Symbol | Value | Description |
|---|---|---|
| Tmin | -20 °C | Operating temperature min. |
| Tmax | 100 °C | Operating temperature max. |
| Code | Description |
|---|---|
| 16,8 mm | Sealing type |
| Standard bearing steel | Material |
| Polyamide cage | Cage |
| Tolerance class P0/PN2 / ABEC 1 | Tolerance class |
FAG UC201 Radial Insert Ball Bearing is an easy-mount ball bearing used in housing units or directly fixed on shafts. Based on deep groove ball bearing geometry, it adds locking devices and seals to simplify maintenance in agricultural machines, conveyors, fans, and handling equipment.
A spherical outer ring and shaft-locking device allow the bearing to compensate for static misalignment when combined with a matching housing. Sealed and lubricated variants are suitable for dusty or wet operating environments.
Check locking method, housing compatibility, seal design, lubrication, contamination level, and load condition.
