NTN
Deep Groove Ball Bearing
RFQ
Estimated delivery: 28 Nov 2026 (domestic stock)
EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.
NTN 6901C3: a deep groove ball bearing with internal clearance C3 (greater than normal) measuring 12 × 24 × 6 mm (bore × OD × width).
Kovar lists 31 NTN variants in the 12×24×6 mm size; the closest to the 6901C3 are 6901 (plain), 6901LLB (non-contact rubber seals on both sides), 6901LLB/2AS (non-contact rubber seals on both sides, Grease fill: Alvania Grease S2). Limiting speed is 32,000 rpm for the 6901C3 versus 27,000 rpm for the 6901LLB.
The same specification comes one size down as 6900C3 (10 mm bore) and one size up as 6902C3 (15 mm bore). Looking for the 6901C3 size from another brand? Options include KOYO 6901, NSK 6901C3, RBC 9301K (check seal and clearance suffixes).
| Symbol | Value | Description |
|---|---|---|
| ≈m | 0.011 kg | Weight |
| Cr | 3200 N | Basic dynamic load rating, radial |
| C0r | 1460 N | Basic static load rating, radial |
| nG | 32000 rpm | Limiting speed |
| Cu | 115 N | Fatigue Load Limit (Cu) |
| Symbol | Value | Description |
|---|---|---|
| d | 12 mm | Bore diameter |
| D | 24 mm | Outside diameter |
| B | 6 mm | Width |
| r | 0.3 mm | Chamfer Dimension, min. (r) |
| ra | 0.3 mm | Max. fillet radius |
| Symbol | Value | Description |
|---|---|---|
| Tmin | -40 °C | Operating temperature min. |
| Tmax | 120 °C | Operating temperature max. |
| Code | Description |
|---|---|
| CN | Radial clearance group |
| Cylindrical bore | Bore type |
NTN 6901C3 Deep Groove Ball Bearing is a versatile rolling bearing for stable, low-friction rotation in a wide range of industrial equipment. It primarily supports radial load while accommodating moderate axial load in both directions, making it a standard choice for motors, pumps, gearboxes, and general machinery.
The bearing consists of inner and outer rings with deep raceway grooves, balls, and a cage. Open, shielded, or sealed designs can be selected according to contamination, lubrication, and maintenance requirements.
Select by bore, outside diameter, width, sealing type, internal clearance, speed rating, and actual radial/axial load conditions.
RFQ
Estimated delivery: 28 Nov 2026 (domestic stock)
Same bearing type, same bore × outside diameter × width, same base designation, and the same seals/shields, bore shape (cylindrical/tapered), internal clearance and precision class. Cage and lubricant may differ — check each product page.
Same bearing type, bore × outside diameter × width and base designation, but seals, internal clearance, bore shape or precision may differ. Check the suffix before ordering.
