SKF 29330 E Self-Aligning Ball Bearing 150 × 250 × 60 mm

Spherical roller thrust bearing with stamped steel cage

Self-Aligning Ball Bearing

RFQ

Restocking soon · Inquire

EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.

Category: Self-Aligning Ball Bearing
Dimensions: 150x250x60mm

Overview

Spherical roller thrust bearing with stamped steel cage

Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.

Key features

High load carrying capacity
Can accommodate combined loads
Allow misalignment or create very stiff bearing arrangements
Long service life and low friction
Separable design

Typical applications

Motors, pumps, and fans
Reducers and industrial gearboxes
Conveyors and handling equipment
General industrial machinery maintenance

Selection guidance

Select by shaft diameter, load direction, speed, mounting space, sealing/lubrication condition, and compatibility with the existing part number.

Symbol	Value	Description
C	1 000 kN	Basic dynamic load rating
C0	2 850 kN	Basic static load rating
reference_speed_rpm	1 500 r/min	Reference speed
limiting_speed_rpm	2 400 r/min	Limiting speed
performance_class	SKF Explorer	SKF performance class

Symbol	Value	Description
d	150 mm	Bore diameter
D	250 mm	Outside diameter
H	60 mm	Height

Symbol	Value	Description
da	min. 195 mm	da
db1	max. 158 mm	db1
db2	max. 163 mm	db2
Da	max. 219 mm	Da
ra	max. 2 mm	ra

High load capacity
Can accommodate combined loads
Allows misalignment or enables a very rigid bearing arrangement
Long service life and low friction
Separable design

Code	Description
고정 기능, 하우징 와셔	None
보어 유형	Cylindrical
케이지	Sheet metal
공차 클래스	Normal
제품 순 중량	10.8 kg
eClass 코드	23-05-11-03
UNSPSC 코드	31171507

datasheet pdf download
