SKF
SKF TKDT10
Precision bearing
RFQ
Estimated delivery: 26 Jul 2026 (overseas stock, ~4 weeks)
In stockEstimated delivery: 26 Jul 2026 (overseas stock, ~4 weeks)
EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.
Overview
Precision bearing
A precision machine element that reduces friction and supports loads in rotary or linear motion. The appropriate type and precision class are selected according to the application and load conditions; accurate dimensions and surface quality provide stable operation and long service life.
Key features
- Supports loads, reduces friction
- Accurate dimensions and surface quality
- Type/class selectable by application
- Stable operation and long life
Typical applications
- Motors, pumps, and fans
- Reducers and industrial gearboxes
- Conveyors and handling equipment
- General industrial machinery maintenance
Selection guidance
Select by shaft diameter, load direction, speed, mounting space, sealing/lubrication condition, and compatibility with the existing part number.
| Symbol | Value | Description |
|---|---|---|
| dim_장비_치수 | 160 x 63 x 30 mm | 장비 치수 |
| dim_케이스_치수_l_x_h_x_w | 530 x 85 x 180 mm | 케이스 치수(l x h x w) |
| Code | Description |
|---|---|
| 계기 무게 | 200 g |
| 권장 보관 온도 | -10 – 60 °C |
| 권장 용도 | Used in applications where an acurate temperature measurement on non moving hard surfaces is required E.g. bearings, bearing housings, pumps, compressors and other machines. Also suited for use with SKF TIH induction heaters for measuring the difference between the bearing inner and outer ring temperatures during bearing heating. |
| 내용 | 1x SKF Thermometer TKDT 101x Contact probe TMDT 2-303x AAA batteries1x printed QR card |
| 디스플레이 | LCD with dual temperature display with switchable backlight |
| 배터리 | 3x AAA (LR03) Alkaline (incl.) |
| 배터리 사용 수명 | 18 hours typical use (backlight on) h |
| 보호 정도(IP) | IP 40 |
| 상대 습도 | 10 to 90% RH non-condensing |
| 연결 | 2x Type-K connectors |
| 자동 꺼짐 | 20 min, off |
| 작동 온도 범위 | 0 – 50 °C |
| 측정 모드 | °C, °F, K |
| 컬러 | 청색, 짙은 회색 |
| 특수 기능 | Min, max, average, differential, dual temperature, hold, timer |
| 프로브 | Supplied with K type probe, TMDT 2-30 included (max. 900 °C)Other probes optional |
| 하우징 재료 | Plastic thermoplastic rubber |
| 해상도 | 0.1 °C/°F (below 999.9)1 °C/°F (above 1000) |
| 제품 순 중량 | 1.11 kg |
| eClass 코드 | 23-05-19-01 |
| UNSPSC 코드 | 41112202 |
