SKF PSM 253020 A51 關節軸承 25 × 30 × 20 mm

燒結青銅直軸套

Spherical Plain Bearing

詢價

即將補貨 · 諮詢

顯示價格為 EX-WORKS（國貿條規 2020）韓國首爾。運費、關稅及保險由買方承擔。

Category: 關節軸承
Dimensions: 25x30x20mm

Overview

燒結青銅直軸套

SKF 燒結銅直式（圓柱形）軸套適用於旋轉、振盪和線性移動，可承受徑向載荷。 SKF 燒結銅軸套為自潤滑和免維護的型號。由浸有礦物油的多孔青銅基體製成。浸油可實現很高的滑動速度，因而適用於旋轉應用。

Key features

幾乎免維護運轉；低摩擦係數；極高滑動速度

Typical applications

Hydraulic cylinder rod ends
Construction machinery linkages
Agricultural joints
Industrial pivot structures

Selection guidance

Check load direction, oscillation angle, relubrication access, sealing need, ring material, and mounting dimensions.

符號	數值	說明
d	25 mm	內徑
D	30 mm	外徑
B	20 mm	寬度

免維護運行
低摩擦係數
極高滑動速度

代碼	說明
설계	直
재료	燒結青銅
재윤활 기능	無
제품 순 중량	0.029 kg
eClass 코드	23-05-01-90
UNSPSC 코드	31171605

資料手冊PDF下載
