SKF
Spherical roller thrust bearing with stamped steel cage
Axial Spherical Roller Bearing
RFQ
EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.
The SKF 29415E is an axial spherical roller bearing, 75 × 160 × 51 mm (bore × OD × width).
Parts from other brands with the same dimensions as the 29415E include FAG 29415, KOYO 29415, NSK 29415, NTN 29415; check that the seal and clearance suffixes match before substituting.
| Symbol | Value | Description |
|---|---|---|
| C | 600 kN | Basic dynamic load rating |
| C0 | 1 430 kN | Basic static load rating |
| nϑr | 2 400 r/min | Reference speed |
| nG | 4 000 r/min | Limiting speed |
| SKF Explorer | SKF performance class | |
| ≈m | 4.52 kg | Weight |
| Symbol | Value | Description |
|---|---|---|
| d | 75 mm | Bore diameter |
| D | 160 mm | Outside diameter |
| H | 51 mm | Height |
| B | 51 mm | Width (B) |
| Symbol | Value | Description |
|---|---|---|
| da | min. 115 mm | da |
| db1 | max. 82.5 mm | db1 |
| db2 | max. 82.5 mm | db2 |
| Da | max. 133 mm | Da |
| ra | max. 2 mm | ra |
| Code | Description |
|---|---|
| 고정 기능, 하우징 와셔 | None |
| Bore type | Cylindrical |
| Cage | Sheet metal |
| Tolerance class | Normal |
| Net weight | 4.52 kg |
| eClass code | 23-05-11-03 |
| UNSPSC code | 31171507 |
Spherical roller thrust bearing with stamped steel cage
Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.
Review axial load, speed, lubrication quantity, cooling, mounting alignment, and minimum load requirements.
