SKF C 4908 V Self-Aligning Ball Bearing 40 × 62 × 22 mm

Full complement CARB toroidal roller bearing

Self-Aligning Ball Bearing

RFQ

Restocking soon · Inquire

EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.

Category: Self-Aligning Ball Bearing
Dimensions: 40x62x22mm

Overview

Full complement CARB toroidal roller bearing

CARB toroidal roller bearings are unique: as well as accommodating misalignment without increased stress levels, they also provide frictionless axial movement within the bearing in the non-locating position in self-aligning bearing arrangements. This full complement bearing, which has a lower speed rating, uses as many rollers as possible, giving it the highest possible load rating.

Key features

Accommodate misalignment and axial displacement within the bearing
Very high radial load carrying capacity
Provide frictionless axial movement
Long bearing system life

Typical applications

Motors, pumps, and fans
Reducers and industrial gearboxes
Conveyors and handling equipment
General industrial machinery maintenance

Selection guidance

Select by shaft diameter, load direction, speed, mounting space, sealing/lubrication condition, and compatibility with the existing part number.

Symbol	Value	Description
C	76.5 kN	Basic dynamic load rating
C0	100 kN	Basic static load rating
limiting_speed_rpm	4 300 r/min	Limiting speed
performance_class	SKF Explorer	SKF performance class

Symbol	Value	Description
d	40 mm	Bore diameter
D	62 mm	Outside diameter
B	22 mm	Width

Symbol	Value	Description
da	max. 52 mm	da
Da	max. 58.8 mm	Da
ra	max. 0.6 mm	ra

Accommodates misalignment and axial displacement within the bearing
Very high radial load capacity
Provides friction-free axial displacement
Long bearing system service life

Code	Description
열 개수	1
로케이팅 기능, 베어링 외륜	None
보어 유형	Cylindrical
케이지	None
경방향 내부틈새	CN
공차 클래스	Normal
씰링	None
윤활유	None
재윤활 기능	None
제품 순 중량	0.24 kg
eClass 코드	23-05-09-13
UNSPSC 코드	31171505

datasheet pdf download
