SKF PER.5206RPP3 Angular Contact Ball Bearing 30.15 × 62 × 50 mm

Special double row angular contact ball bearing with round bore, cylindrical outer surface and high contamination resistant seals

Angular Contact Ball Bearing

RFQ

Restocking soon · Inquire

EX-WORKS (Incoterms 2020) Seoul, Korea — Buyer arranges freight, duties, and insurance.

Category: Angular Contact Ball Bearing
Dimensions: 30.15x62x50mm

Overview

Special double row angular contact ball bearing with round bore, cylindrical outer surface and high contamination resistant seals

These special double row angular contact ball bearings are designed mainly for agricultural applications, are commonly used in agricultural seeding equipment, such as grain drills or planters. The integral sealing and higher-than-standard grease fill can significantly prolong bearing service life and reduce maintenance efforts.

Key features

Designed mainly for agricultural applications
Round bore
Accommodate relatively high radial loads and large axial loads in both directions
Integral sealing and higher-than-standard grease fill prolongs bearing service life

Typical applications

Machine tool spindles and support shafts
Pumps and compressors
High-speed motors
Precision gearboxes and robot drives

Selection guidance

Select by contact angle, arrangement, preload, precision class, axial load direction, and operating speed.

Symbol	Value	Description
C	29 kN	Basic dynamic load rating
C0	20.7 kN	Basic static load rating

Symbol	Value	Description
d	30.15 mm	Bore diameter
D	62 mm	Outside diameter
B	50 mm	Width

Mainly designed for agricultural use
Cylindrical bore
Accommodates relatively high radial loads and large axial loads in both directions
Integrated sealing and higher-than-standard grease fill extend bearing service life

Code	Description
열 개수	2
씰링 유형	Contact type
윤활유	Grease
제품 순 중량	0.495 kg
